Ashok Leyland 12M Bus
Ashok Leyland 12M is a premium intercity bus built to meet global standards.
Key Highlights
The Ashok Leyland 12M offers a 197 hp H-series or 248 hp A-series i-Gen6 engine, air suspension, and sleeper or push-back seating.
Two i-Gen6 Engines
197 hp H-series or 248 hp A-series engine with flat torque for every route.
Air Suspension
Rear air suspension, with front air suspension available, for a smooth ride.
Superior Ride Comfort
Four-bellow air suspension and premium seats for a smooth journey.
Advanced Braking System
ABS, engine brake, disc option, and retarder for total control.
Sleeper or Push-Back
30+D sleeper berths or 44+D push-back seats for long-distance travel.
Low Maintenance
Unitised bearings and tubeless tyres mean fewer stops, more uptime.
Technical Specifications
| Model | 12M Viking (TF2012.0T6R) | 12M Viking Air-Air (TF2512.0F6R) |
|---|---|---|
| Engine | H series, 6 cylinder diesel CRS BS-VI | A series, 4 cylinder diesel CRS BS-VI |
| Maximum Power | 147 kW (197 hp) @ 2400 rpm | 185 kW (248 hp) @ 2200 rpm |
| Maximum Torque | 700 Nm @ 1200–1900 rpm | 900 Nm @ 1100–1800 rpm |
| Clutch | 380 mm diameter diaphragm type with air assisted hydraulic actuation | |
| Transmission | 6 speed synchromesh with overdrive, cable shift system | |
| Front Suspension | Rubber ended leaf spring / Air suspension | |
| Rear Suspension | Air suspension | |
| Steering | Integral power assisted, tilt and telescopic option | |
| Rear Axle | Fully floating single reduction hypoid with unitized bearing option | |
| Brakes | Full air brakes dual line 'S'-cam with ABS, front disc option | |
| Tyres | 295/80 R 22.5 – 16 PR tubeless | |
| Electricals | 24V – 150 Ah / 200 Ah (EMR Variant) Battery 85 A / 100 A (A.C. variant) Alternator |
24V – 150 Ah / 200 Ah (EMR variant) Battery 100 A Alternator |
| Fuel Tank | 350 L, aluminized steel tank | |
| Auxiliary Brake | Exhaust brake, Electro magnetic retarder option | Engine brake, Electro magnetic retarder option |
| A.C. | Provision for direct drive A.C. | |
| DEF Tank | 24 L | |
| Wheelbase | 6000 mm | |
| Front Overhang | 2265 mm | |
| Rear Overhang | 3500 mm | |
| Overall Length | 11765 mm | |
| GVW | 16200 kg | 17500 kg |
| Indicative Seating Capacity | 2×1 – 30+D Sleeper Berth, Single Door | 2×2 – 44+D Push back seats, Single Door | |
